Chapter 1 : The Frame Structure of Low Bed Trailer for Sale

Chapter 2 : What are the Safty Measures of Semi Low Bed Trailer?

Chapter 3 : How Good is the Ramp of 3 Axle Low Bed Trailer?

Chapter 4 : What are the Gooseneck designs of 40 Feet Low Bed Trailer?

---

Chapter 1 : The Frame Structure of Low Bed Trailer for Sale

1. Side beam

Simba semi low bed trailer:

The side beam height of Simba low bed trailer for sale is 200mm and the width is 70mm. The side beam of the low bed trailer price is made of channel steel, which is suitable for transporting light goods. If you are in some narrow transportation environments, the narrower side beam can make the 3 axle low bed trailer more flexible when passing through narrow roads in Tanzania.

When using forklifts or lifting equipment, the reduction in the height of the side beam makes the cargo loading and unloading process of the 40 feet low bed trailer more convenient, effectively improving the operating efficiency.

TITAN semi low bed trailer:

Since TITAN uses T700 high-strength structural steel, the side beam of the low bed trailer for sale is designed with more emphasis on higher carrying capacity. Not only that, the cross-section design of Titan's side beam is reasonable and has better structural performance. The low bed trailer price finds a dynamic balance between load capacity and deadweight at the same time.

2. Main beam

Simba 40 feet low bed trailer:

The main beam on the Simba 3 axle low bed trailer made of Q345 steel is relatively simple. With the main beam with a width of 140 mm for the upper and lower wings, it is particularly suitable for transporting goods under 100 tons.

TITAN 40 feet low bed trailer:

TITAN's main beam adopts a more complex combined structure, with a width of 220 mm for the upper and lower wings. The steel of the main beam has been optimized and upgraded to HG60 steel, which improves strength and toughness. The bending and torsional rigidity of the semi low bed trailer's main beam has been effectively enhanced to ensure transportation safety under various heavy-load conditions in Tanzania.

3. Rear axle upper vertical plate

Simba low bed trailer for sale:

The Simba rear axle upper vertical plate design is relatively simple, using flat plates, which can meet the basic light cargo load requirements. In order to adapt to different transportation needs in Tanzania, the unreinforced vertical plate can be easily removed. It makes the low bed trailer price more flexible when loading and unloading goods in Tanzania. The unreinforced vertical plate will provide the driver with a better field of vision in Tanzania.

TITAN low bed trailer for sale:

TITAN adopts a thickened vertical plate design to enhance the structural stability of the rear axle. Not only the inside of the three-axle vertical plate of the 3 axle low bed trailer is reinforced, but the outside of the vertical plate is also partially reinforced. When the 3 axle low bed trailer transports heavy goods, this design can prevent deformation and improve the impact resistance of the low bed trailer price.

40 Feet Low Bed Trailer Price | 3 Axle Low Bed Trailer for Sale in Tanzania

4. Connection between the beam and the side beam



Simba semi low bed trailer:

At the connection between the beam and the side beam, in order to reduce the dead weight while meeting the basic strength requirements, Simba uses a simple welding process. But it is relatively easy to be affected in terms of seismic resistance and durability.

TITAN semi low bed trailer:

In order to prevent the left and right deformation of the beam caused by the downward pressure of the side beam of the low bed trailer for sale, TITAN strengthens the connection between the beam and the side beam. This characteristic reinforced connection process increases the durability and stability of the entire structure of the low bed trailer price. When transporting heavy loads in Tanzania, fatigue of the 3 axle low bed trailer due to connection components can be prevented in advance.

5. Diagonal support

Simba low bed trailer price:

Speaking of the design of diagonal support, Simba's structure is relatively simple, mainly playing a basic supporting role, but it is slightly insufficient in terms of tilting force and stability in Tanzania.

TITAN low bed trailer price:

By using reinforced and thickened diagonal support, Titan 3 axle low bed trailer has a stronger load distribution ability and overall stability. The design of the diagonal support is more scientific and has the same structure as the main beam. The 6mm diagonal support is made of HG60 high-strength steel, which is also the same material as the main beam. Although this design increases the cost of consumables, when the goods on the 3 axle low bed trailer are unevenly distributed, it reduces its tilting risk.

Please make a comprehensive consideration based on your specific cargo characteristics and actual road environment in Tanzania.

Chapter 2 : What are the Safty Measures of Semi Low Bed Trailer?

1. Floor reinforcement

Simba low bed trailer for sale: 4mm patterned plates

Advantages: By using 4mm thick patterned plates as floor plates, Simba semi low bed trailers can effectively improve the anti-skid performance of low bed trailer for sale while ensuring a certain strength. The pattern design increases friction and reduces the phenomenon of goods sliding and breaking on low bed trailer price. This thickness is suitable for heavy-duty transportation with lower weight requirements, allowing 3 axle low bed trailers to meet the basic safety needs in Tanzania.

TITAN low bed trailer for sale: 5mm patterned plates

Advantages: Compared with Simba, the 5mm thick patterned plates provide 40 feet low bed trailers with superior load-bearing capacity and anti-deformation capabilities. In the relatively difficult heavy-duty process, the thicker floor plate can disperse the pressure on the 40 feet low bed trailer. During transportation, the thick floor plate further reduces the consequences of fatigue damage to the floor plate of the 40 feet low bed trailer. The floor provides greater safety while allowing it to be used longer. At the same time, when the force is uneven, the 5mm thickness can help the semi low bed trailer better resist unexpected impacts, especially for the beginning of heavy cargo transfer.

2. Reinforcement above the tire

Simba 3 axle low bed trailer: no reinforcement measures for the side beam uprights above the tire

Advantages: Although Simba's side beam uprights above the tires have no reinforcement measures, its simple design is more suitable for the needs of lighter heavy-duty transportation in Tanzania. This simple design of the low bed trailer for sale is relatively easy to adapt to different goods and transportation environments in Tanzania.

TITAN 3 axle low bed trailer: the entire side beam upright above the tire is reinforced by double webs

Advantages: TITAN's double web reinforcement design above the tire provides the most powerful support for the side beam uprights. This design can effectively resist the impact and lateral pressure from above while significantly improving the strength and stability of the side beams of the low bed trailer price. Reduces various potential safety risks of 3 axle low bed trailers when transporting large equipment. In addition, this reinforcement design improves the stability of low bed trailer price in complex road conditions in Tanzania by enhancing the safety of the load.

40 Feet Low Bed Trailer Price | 3 Axle Low Bed Trailer for Sale in Tanzania

3. Suspension reinforcement

Simba semi low bed trailer: light suspension and 45mm center pin

Advantages: With a simpler and lighter suspension design, Simba low bed trailer for sale are particularly suitable for general transportation needs in Tanzania. The 45mm center pin has good flexibility, making Simba low bed trailer for sale widely used in the transportation of small and medium-sized goods. Although this safety performance is relatively low, it has more advantages in terms of operating costs due to the reduction of the initial purchase cost of the 40 feet low bed trailer.

TITAN semi low bed trailer: reinforced suspension and 70mm center pin

Advantages: The combination of TITAN's reinforced suspension and 70mm center pin provides higher load-bearing capacity and stability in Tanzania. During driving, the reinforced suspension can better reduce the damage to the goods caused by road bumps in order to maintain the stability of the 40 feet low bed trailer transportation process. For the driver, this suspension makes the low bed trailer for sale a more comfortable driving experience. Under heavy load conditions, the enhanced support capacity corresponding to the 70mm center pin can better maintain the vehicle's maneuverability and safety in Tanzania.

Through comparison, it can be seen that the design of TITAN improves overall safety and is suitable for heavy cargo transportation and use in complex environments in Tanzania. In terms of operational flexibility and cost control, Simba 3 axle low bed trailers also have their own unique advantages, suitable for light cargo transportation and economic needs.

40 Feet Low Bed Trailer Price | 3 Axle Low Bed Trailer for Sale in Tanzania

Chapter 3 : How Good is the Ramp of 3 Axle Low Bed Trailer?

1. Materials

Simba low bed trailer price: channel steel, single-layer steel, hollow structure

Advantages: With the channel steel material used in the ladder, Simba has a preliminary load-bearing capacity. For low bed trailer for sale, the design of single-layer steel reduces weight while facilitating the lightweight of the entire body, which is suitable for loading and unloading small and medium-sized equipment. The ladder with a hollow structure improves the 40 feet low bed trailer's anti-deformation ability to a certain extent, but it may be relatively insufficient when carrying heavier equipment in Tanzania.

TITAN low bed trailer price: H60 steel, four-in-one high-strength plate, double-layer steel

Advantages: With high-strength H60 steel and four-in-one high-strength plate, TITAN improves the strength and durability of the ladder. The design of double-layer steel in the ladder not only enhances the load-bearing capacity of the low bed trailer for sale, but also greatly improves the impact resistance. This means that for the loading and unloading of heavy equipment in Tanzania, TITAN's ladder can withstand greater pressure.

2. Springs

Simba 3 axle low bed trailer: ordinary springs

Advantages: After using ordinary springs, although Simba can achieve basic ladder functions, it is relatively average in terms of ease of operation and stability under load. When lowering or raising the ladder, the user may need to adjust the strength several times, and the overall semi low bed trailer operation is more laborious.

TITAN 3 axle low bed trailer: high-quality springs

Advantages: Thanks to the high-quality springs equipped with TITAN, the lowering and raising of the ladder have become extremely convenient in Tanzania. Only one person can easily complete the ladder operation of the semi low bed trailer. After the spring design is optimized, ordinary people can lift the ladder of the 40 feet low bed trailer with one hand. This greatly improves the efficiency and safety of the low bed trailer price operation, and is very suitable for work occasions that require frequent loading and unloading of equipment.

40 Feet Low Bed Trailer Price | 3 Axle Low Bed Trailer for Sale in Tanzania

3. Applicability

Simba low bed trailer for sale: suitable for small and medium-sized equipment

Advantages: In response to the transportation needs of small and medium-sized equipment, Simba's ladder design is mainly suitable for light loading and unloading, and is convenient for the entry and exit of small and medium-sized equipment. When used in general venues, this targeted design can play a better role. However, the performance of low bed trailer for sale is limited in heavy applications in Tanzania.

TITAN low bed trailer for sale: Suitable for both small and medium-sized equipment and excavators or other heavy equipment

Advantages: TITAN's ladder design has been added with more functions. The 40 feet low bed trailer is not only suitable for small and medium-sized equipment, but also can easily handle the loading and unloading of heavy equipment such as excavators. With strong materials and high-quality spring design, the overall application range of Titan 3 axle low bed trailer is wider. In order to meet the needs of different transportation occasions in Tanzania, 3 axle low bed trailer are designed to be more flexible and practical.

TITAN has higher reliability and safety in every aspect. Simba is more economical and easy to operate in terms of lightweight and small and medium-sized equipment transportation in Tanzania.

Chapter 4 : What are the Gooseneck designs of 40 Feet Low Bed Trailer?

1. Gooseneck shape

Simba gooseneck:

Design features: The gooseneck design of Simba is pressed down at the edge of the tail, and the rest of the part remains straight. Although this design is suitable for transporting small and medium-sized equipment, it has certain limitations.

Due to the low height of the gooseneck, it is easy to cause the low-profile truck to tilt when transporting heavy goods, resulting in uneven force and increasing the difficulty of climbing the goods in Tanzania. When facing a large load, this shape may cause stability problems of the 3 axle low bed trailer and affect the overall transportation safety in Tanzania.

TITAN gooseneck:

Design features: With the downward pressure design, the gooseneck height of the TITAN low bed trailer price is generally higher. Under heavy load conditions, this design significantly reduces the probability of tilting and ensures the stability of the low bed trailer price. When climbing, the higher gooseneck can also provide the low bed trailer for sale with better center of gravity control and reduce the impact on the handling of the low bed trailer for sale.

40 Feet Low Bed Trailer Price | 3 Axle Low Bed Trailer for Sale in Tanzania

2. Vertical plate under the gooseneck

Simba gooseneck:

Structural features: There is no vertical plate reinforcement under the gooseneck of Simba, that is, between the two main beams below.

When overloaded, this design can reduce the weight of the semi low bed trailer, but lacks the necessary support. It is easy to cause the low bed trailer price to deform under a large load. When facing greater pressure, the unreinforced structure under the gooseneck may affect the stability and safety of the semi low bed trailer, increasing the risk of transportation in Tanzania.

TITAN gooseneck:

Structural features: Compared with Simba, TITAN has made reinforcements in the design under the gooseneck, that is, the double-layer vertical plate is configured between the two main beams below.

Under heavy loads, the structural strength and stability of the low bed trailer for sale are significantly enhanced, and the reinforcement design makes the deformation of the low bed trailer price very small. This reinforcement measure not only improves the carrying capacity of the 3 axle low bed trailer when passing through complex road conditions in Tanzania, but also enhances the safety of the 3 axle low bed trailer.

When transporting heavy equipment, TITAN's 40 feet low bed trailer is more stable and safe through the reinforcements. When transporting small and medium-sized equipment, the Simba 40 feet low bed trailer is designed to be light, but it seems a bit insufficient when facing heavy goods.
