60 Ton Lowboy Gooseneck Trailer

Lowboy Trailer Price:

TITAN 60 ton lowboy trailer for sale has many different names in different countries around the world, such as lowboy trailer price, lowboy gooseneck trailer for sale, 60 ton lowboy trailer for sale.

Loading method of lowboy trailer price: cargo is loaded from the front. TITAN Lowboy gooseneck trailer for sale cargo table is only 85 cm, the center of gravity is very low, so the stability and security are very good. As you can see, our 60 ton lowboy trailer for sale can transport ultra-high and medium sized equipment and machine.

Lowboy Trailer Price | 60 Ton Lowboy Gooseneck Trailer for Sale

Lowboy Trailer Price | 60 Ton Lowboy Gooseneck Trailer for Sale

Lowboy Trailer Price | 60 Ton Lowboy Gooseneck Trailer for Sale

Lowboy Trailer Price | 60 Ton Lowboy Gooseneck Trailer for Sale

Specification of lowboy trailer price:

Dimension: 15800mm x 3000mm x 2500mm

Loading capacity(T): 50-150T

Lowboy Trailer Price Axle: 3 axle

Tire: 12 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension or air suspension

Spring leaf: 120(W)mmx16(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

60 Ton Lowboy Trailer Tare weight: About 9.5-19T

Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.

Bottom Platform: 5mm thick, checkered plate

Hydraulic cylinder: 12KW diesel engine with hydraulic station

Ramp: spring or hydraulic type

60 Ton Lowboy Trailer ABS: Optional

Lowboy Trailer Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Lowboy Gooseneck Trailer Voltage: 24V

60 Ton Lowboy Trailer Tool box: 1 set

Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust

Through the video, you can know different types of 60 ton lowboy trailer for sale, etc.

Please click "TITAN Removable Gooseneck Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
