4 Axle Folding Lowboy Gooseneck Trailers

4 Axle Folding Lowboy Gooseneck Trailer Product Description:

The folding gooseneck lowboy trailer is a front-loading trailer, and unlike the RGN trailer, the lowboy gooseneck trailer can be loaded from the front of a low-level trailer (also a flatbed trailer) without removing the gooseneck from the body. Widely used in the transportation of construction machinery, with or without crawler tires.

The gooseneck trailer with foldable neck allows you to easily move heavy machinery even without a crane to lift it. The neck of the folding gooseneck trailer for sale can be folded to the ground to serve as a shallow slope for crawler cranes and other machines to travel. It is one of the popular front loading trailers, the other is the detachable gooseneck trailer.

This model has high requirements on the gooseneck, because it is the main load-bearing part of the heavy machinery. So we will use strong high-strength steel.

4 Axle Folding Lowboy Gooseneck Trailers For Sale in Ghana

4 Axle Folding Lowboy Gooseneck Trailers For Sale in Ghana

Specification:

Dimension: 18000mm x 3800mm x 1800mm

Working platform: 14000*3800MM

Loading capacity: 100 TONS.4 AXLES,16TONS.

Gooseneck: hydraulic folding gooseneck.

Side hook for chain or belt

Checkered plate with 20 mm squre bar on ramps

Twist locks :6 units for 40/45 ft container

Axle: 4 Axle

Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension or air suspension

Spring leaf: 120(W)mmx16(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Tare weight: About 9.5-19T

Hydraulic cylinder: 12KW diesel engine with hydraulic station

Ramp: spring or hydraulic type

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust

Through the video, you can know different types of gooseneck trailers, as well as the process, testing, packaging and customer feedback, etc.

Please click "TITAN Removable Gooseneck Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
