100 ton Folding Gooseneck
100 ton Folding Gooseneck 100 ton Folding Gooseneck 100 ton Folding Gooseneck

100 ton Folding Gooseneck

27000 USD

Different Parameters, Different Price. Price Reference Only.



100T Folding Gooseneck Trailer is widely used for transporting construction machines no matter they are with tires of crawlers or not.

SKU: 100T Folding Gooseneck Trailer
MPN: TITAN9409098
Brand: TITAN

100T Folding Gooseneck Trailer Product Description:

Folding gooseneck trailer is a kind of front-loading trailer, different from the RGN trailer, you can load the trailer from the front of the lowbed trailer(could be flatbed trailer) but no need to dismantle the gooseneck from the trailer body. It is widely used for transporting construction machines no matter they are with tires of crawlers or not.

Lowbed trailer with a foldable neck makes you move construction machines easily even without crane’s lifting. When unhooking from the prime mover, the semi trailer’s neck could be folded to ground as a shallow slope for crawler crane and other machines to drive on. It is one of the popular front loading trailers, another one is detachable gooseneck trailer.

4 Axle Hydraulic Folding Gooseneck Trailer for Sale in Nigeria

4 Axle 100T Hydraulic Folding Gooseneck Trailer

4 Axle Hydraulic Folding Gooseneck Trailer for Sale in Nigeria

100T Folding Gooseneck Trailer

4 Axle 100T Hydraulic Folding Gooseneck Trailer for Sale in Nigeria

4 Axle 100T Hydraulic Folding Gooseneck Trailer for Sale



Specification:

Dimension: 18000mm x 3800mm x 1800mm

Working platform: 14000*3800MM

Loading capacity: 100 TONS.4 AXLES,16TONS.

Gooseneck: hydraulic folding gooseneck.

Side hook for chain or belt

Checkered plate with 20 mm squre bar on ramps

Twist locks :6 units for 40/45 ft container

Axle: 4 Axle

Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension or air suspension

Spring leaf: 120(W)mmx16(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Tare weight: About 9.5-19T

Hydraulic cylinder: 12KW diesel engine with hydraulic station

Ramp: spring or hydraulic type

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust

folding gooseneck trailer drawbar

Folding Gooseneck Trailer Package

folding gooseneck trailer



Through the video, you can know different types of gooseneck trailers, as well as the process, testing, packaging and customer feedback, etc.

4 Axle Hydraulic Folding Gooseneck Trailer for Sale in Nigeria

Please click "TITAN Removable Gooseneck Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!



Review

Gary Petras from Philippines - 2022-01-05T11:01:07+0800
The 100-ton folding gooseneck is very good. I have used it for more than three months, it has no quality issues.
Nikolay Galyuk from Malawi - 2021-12-09T14:12:43+0800
I have received this 100t folding gooseneck trailer and I like it very much. First of all, the appearance is very beautiful, and the sales service attitude is very good, and the most important thing is that the quality of the trailer is very good.
Chibuigwe from Nigeria - 2021-11-01T16:11:56+0800
It's the first time I try 100t folding gooseneck trailer. If I need it next time, I will consider buying a TITAN semi trailer.
Kely Elvis from Uganda - 2021-10-20T16:10:25+0800
This is a really great 100T folding gooseneck trailer. TITAN adopts the latest hydraulic connecting pin to connect the deck with the gooseneck, easy, convenient and safe for operator.
