Detachable Gooseneck Lowboy Trailer

Detachable Gooseneck Lowboy Trailer Product Description:

The series of detachable gooseneck lowboy trailer have flat, concave beam and tire leakage structures. The frame is stepped and the longitudinal beam section is I-shaped, which has the characteristics of rigid height and strong height. The low plane of the truck rack and column ensures the stability of transportation and is suitable for carrying all kinds of construction machinery, large equipment and steel. The lowboy semi trailer is used for pulling mechanical equipment, large-scale equipment such as excavators, bulldozers, etc.

The second and third bridges can be equipped with 30 tons, 50 tons, 60 tons, 80 tons, 100 tons, 120 tons, and 300 tons. Pulling and optional hydraulic ladder trucks have a low level of shelf and column to ensure the stability of transportation and are suitable for carrying all kinds of construction machinery, large equipment and steel.

Specification:

Dimension: 15800mm*3000mm*2500mm

Loading capacity(T): 50-150T

Axle: 3 axle; 13T/16T, FUWA / BPW / TITAN Brand

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension or air suspension

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Tare weight: About 9.5-19T

Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.

Bottom Platform: 5mm thick, checkered plate

Hydraulic cylinder: 12KW diesel engine with hydraulic station

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust

Through the video, you can know different types of 3 axle detachable gooseneck lowboy trailer , 80ton detachable gooseneck trailer , detacahble gooseenck lowboy trailer for sale, etc.

Please click "TITAN Removable Gooseneck Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
