40ft Gooseneck Skeleton Trailer
40ft Gooseneck Skeleton Trailer

40ft Gooseneck Skeleton Trailer

6700 USD

Different Parameters, Different Price. Price Reference Only.



Each 40ft Gooseneck Skeleton Trailer can be custom designed to fit your individual needs. Different Gooseneck Skeleton Trailer models will be recommended according to the market demand.

SKU: 40ft Gooseneck Skeleton Trailer
GTIN: 6975766113711
MPN: TITAN9401043
Brand: TITAN

Product description:

40ft Gooseneck Skeleton Trailer can transfer the cargo directly from the truck to another means of transportation. Rapid load and unload allow drivers to deliver the goods to customers in a fast manner.

We are a specialist in the design and production of Skeleton Trailer. Each 40ft Gooseneck Skeleton Trailer can be custom designed to fit your individual needs. Different Gooseneck Skeleton Trailer models and configurations will be recommended according to the market demand.

40ft Gooseneck Skeleton Trailer

40ft Gooseneck Skeleton Trailer

40ft Gooseneck Skeleton Trailer



Gooseneck Skeleton Trailer Specifications:

Dimension(mm): 12400x2500x1500mm

Loading capacity(ton): ≤60T

Axles: 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand

Tire: 13 units, 12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Suspension: Mechanical suspension or Air suspension

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)

Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel

Side Beam: 16mm or 18mm steel channel (material: Q235 steel)

Platform: 3mm-thick checkered plate

Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank

Twist Locks: 4,8,12 sets (lifting or screw type)

Valve: WABCO valve (specially intended for oversea market)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats

Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)

Shipping Terms: Transported by the bulk carrier in an RORO or 40ft container
