40Ft Side Lifter Trailer will be shipped to East Timor

40Ft Side Lifter Trailer for Sale In East Timor40Ft Side Lifter Trailer for Sale In East Timor

East Timor customers bought our 40ft side lifter trailer again. Customers got to know us through referrals from local friends. The customer also uses the TITAN side lifter trailer locally. Therefore, the customer thinks that our side lifter trailer is of very good quality, so they find us to cooperate. Our technology for producing 40ft side lifters is very mature.

TITAN has a lot of customers using sidelifter trailers in East Timor. So customers trust TITAN very much. Not only because of good quality, but also very good service.

40Ft Side Lifter Trailer for Sale In East Timor40Ft Side Lifter Trailer for Sale In East Timor

How to use 40ft side lifter to load and unload containers?

Place the semi-suspension trailer in an appropriate position close to the container, and keep a distance of 300mm~500mm between the trailer and the container. Open the engine control box, start the engine, let the engine idle for about 10s, and then adjust the 1600r/min~2600r/min through the adjustment handle;

Power on the remote control and the electrical system control box. Adjust and replace equipment, placing front and rear lifting equipment in the correct position. When the 40ft side lifter is hoisted, the slide cylinder of the replacement unit is fully extended, and when the 20ft side lifter is hoisted, the replacement unit is fully enclosed.

Extend the inclined stabilizer legs. Do not operate the boom until the stabilizer legs are fully supported. Open the side lifter to a suitable position, lock the four chain locks at the bottom of the container, use the remote control to control the boom, lift the container and install it on the semi-trailer, rotate the rotation lock without interference to lock the container, and retract the boom in turn and stabilizer. Adjust engine speed to idle and shut off the engine, turning off all power.

40Ft Side Lifter Trailer for Sale In East Timor40Ft Side Lifter Trailer for Sale In East Timor

40Ft Side Lifter Advantage

1. Intelligent safety protection system intelligently cut off dangerous operations; with full side loading container safety control device, with key switch

2. The imported central lubrication system is installed, and the electrical control is simple; the structural parts are made of high-strength steel, and the parts are tested for stress.

3. With no-load and heavy-load dual-speed; dual-pump dual-circuit, not affected by an unbalanced load

4.40ft side lifter can move back and forth, so it can lift both 20' and 40' containers at the same time

5. Using wireless remote control system, imported brand-name controller, simple operation, reliable micro-movement, and manual operation is still reserved in emergency situations; the electromagnetic proportional value is imported, and the operation is accurate

40Ft Side Lifter Trailer for Sale In East Timor40Ft Side Lifter Trailer for Sale In East Timor

The 40ft side lifter can handle 20-40ft containers more easily and efficiently. The first stage of processing involves grounding the vessel.

The 40ft side lifter takes only a few minutes to load or unload a container and it eliminates the lengthy time and effort required to coordinate the work between the trailer driver and crane operator. The main advantage of using this system is that the whole process takes place on the ground, which is fast and safe. This also reduces the likelihood of accidents for workers and damage to goods.

Completed by a 40ft side lifter, the container is a trailer with cranes on both ends. This arrangement allows containers to be loaded or unloaded from the ground.

40Ft Side Lifter Trailer for Sale In East Timor40Ft Side Lifter Trailer for Sale In East Timor

You can download video, you can learn about different types of sidelifter trailers, including 20ft self loader truck, 20ft sidelifter and 40ft container side loader trailer, as well as the process, testing, packaging and customer feedback, etc.

Side Lifter Truck Trailers Video



This kind of semi trailer was designed with lots of advantages and features. If you want to get more information, please don't hesitate to make contact with us.
