U Type Semi Trailer Tipper
U Type Semi Trailer Tipper

U Type Semi Trailer Tipper

17500 USD

Different Parameters, Different Price. Price Reference Only.



TITAN Hydraulic U Type Semi Trailer Tipper for sale has different load capacities, We can customize the semi trailer tipper according to your special need.

SKU: U Type Semi Trailer Tipper
GTIN: 6975766111175
MPN: TITAN9407043
Brand: TITAN

U Type Semi Trailer Tipper Product description:

The Hydraulic U Type Semi Trailer Tipper for sale could bear the bad road conditions. We reinforce the sides with high tensile strengthening rip and the channel steel reinforced enclosure shape design.

The sides are welding molding which increasing the loading capacity. The Hydraulic U Type Semi Trailer Tipper could be used for nearly 10 years. TITAN Hydraulic U Type Semi Trailer Tipper for sale has different load capacities: 24 cubics, 30 cubics, 35 cubics, 45 cubics, We can customize the semi trailer tipper according to your special need.

U Type Semi Trailer Tipper for Sale in Philippines

U Type Semi Trailer Tipper for Sale in Philippines

U Type Semi Trailer Tipper for Sale in Philippines



Semi trailer tipper Specifications:

Dimension: 9300mmx2500mm x3700mm ( inside dimension )

Main beam: Height: 480mm, Upper plate: 14mm, Middle plate: 8mm, Lower plate: 14mm, Material: T700 steel.

Bottom Platform: 4 thick checkered plate

Side wall thickness: 4mm

Total volume(m³): 40m³

End plate: 8mm

Lifting System: Full set of HYVA lifting cylinder

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Toolbox: 1 set





Through these videos, you can learn about different types of semi tipper trailers, as well as the process, testing, packaging and customer feedback, etc.



tipper trailer



Please click " TITAN Tipper Semi Trailer" to get detailed videos!



Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!

Review

Noluthando from Kenya - 2022-04-20T14:04:40+0800
Because I saw the local TITAN dump semi trailer. So I consulted Alice about the dump semi trailer details. They are very professional. That's why I bought the TITAN 60 tom dump semi trailer.
George migenda from Senegal - 2022-03-07T10:03:06+0800
We received tipper semi trailer of very good quality. Especially when dealing with large jobs. Through a carefully designed unloading mechanism, operation safety can be well maintained.
Ahoulou Claude from Burkina Faso - 2021-12-16T14:12:11+0800
I like TITAN tipper semi trailer very much. It is not only of good quality but also guaranteed. If you have any questions, Jacky can answer your questions quickly.
Sabry from Botswana - 2021-12-14T15:12:19+0800
I have made some transport business with the 80 ton dump trailer, and everything is as expected. It is very nice, thanks William
John Morea from Djibouti - 2021-11-17T11:11:41+0800
Recommend TITAN semi dump trailer. We often visit TITAN semi trailer locally. Visible very well-known professional suppliers. I asked TITAN to customize an 80 ton dump trailer. It can meet my needs.
Bongani Sanie - 2021-06-21T11:06:08+0800
Overall the construction seems solid, using quality components.4 units flip brackets, which can make the rear end more evenly loaded during unloading, and it is not easy to damage the tipper trailer. It looks very nice.
