Tri Axle Low Loader Trailer

Tri Axle Low Loader Trailer for sale:

TITAN tri axle low loader trailer for sale price are widely used in heavy machine transportation. Low Loader Trailer for Sale with Hydraulic Ramp, three styles of low loader trailer for sale ramps, the most common is spring ramp. There are also ordinary hydraulic ramps and folding hydraulic ladders.

TITAN produce very durable low loader price with high strength to meet the transport needs. We use high strength steel material to ensure the capacity, our low loader trailer for sale load capacity can be up to 60 to 150 ton payload.

Low Loader Price | Tri Axle Low Loader Trailer for Sale

Low Loader Price | Tri Axle Low Loader Trailer for Sale

Low Loader Price | Tri Axle Low Loader Trailer for Sale

Specification of low loader price:

Overall dimension: 13000mm * 3000mm *3400mm

Loading capacity(T): 40-100T

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20

Tire: 11.00R20

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.

Bottom Platform: 5mm thick checkered plate

Ramp: hydraulic type

Gooseneck: Optional

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Advantages of low loader for sale:

1. Tri axle low loader trailer for sale main beam adopts HG high strength steel, with high loading capacity.

2. Side beam adopt “H” steel, the durable design avoid the low loader price side beam to have the deformation.

3. The  low loader trailer for sale loading ramps is made by high strength steel, with high loading capacity, will not happen to the deformation when carry heavy equipment.

4. polyurethane paint, with long service life, and avoid the vehicle get rust.

5. World famous brand spare part, ensure high quality and save costs.

Tri axle low loader trailer for sale details display video

Through this videos, you can learn about different types of lowbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.

Please click "TITAN Lowbed Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
