Tri Axle 40ft Flatbed Trailer for Sale In Tanzania

This is the second time Tanzanian customer to cooperate with TITAN. In January, the customer ordered 2 units of flatbed trailer. In October, the customer found the sales manager Sunny again and expressed his desire to order tri axle flatbed trailer with ABS again. Abbreviation for Lock Brake System. It is a very important safety device on the flatbed semi trailer.

Used to prevent wheel lock and drag when braking tri axle 40 ft flatbed trailer to improve directional stability, steering maneuverability and shorten braking distance of tri axle 40 ft flatbed trailer during braking, so as to fully utilize the car braking efficiency. So customers need to upgrade to tri axle 40 ft flatbed trailer with ABS on the basis of the previous configuration.

The following is a detailed introduction to the correct use and maintenance of tri axle 40 ft flatbed trailer ABS.

Tri Axle 40ft Flatbed Trailer for Sale In Tanzania

Flatbed Trailer ABS Use and Care

1. When washing the car, do not directly flush the combination valve or the controller (ECU) with water, which may cause the ABS system to malfunction due to water ingress.

2. When welding the tri axle 40 ft flatbed trailer, the ABS power cable must be unplugged, otherwise, the controller (ECU) may be damaged.

3. Ensure that there is no air leakage or insufficient air pressure in the braking air path of the tractor, and ensure that the conventional braking of the tractor is normal.

4. The Tri axle 40 ft flatbed trailer is equipped with a pipeline filter, which needs to be cleaned once every three months to ensure that the pipeline is clean to prevent damage to the ABS.

5. Always check whether the sensor connector of the tri axle 40 ft flatbed trailer is loose. If it needs to be replaced, it must not be inserted wrongly. It is necessary to ensure that the air circuit corresponds to the sensor, and the same side of the brake air pipe corresponds to the combination valve or the same side of the solenoid valve.

6. When emergency braking on wet and slippery roads, there is no need to use continuous jogging of the brake pedal, only full braking is required.

7. Since most braking is conventional braking, tri axle 40 ft flatbed trailer ABS does not participate in the braking process, so it generally does not cause high temperature of the wheels, but abnormal high temperature may affect the sensor.

8. In case of failure, the user cannot dismantle the components of the tri axle 40 ft flatbed trailer ABS system by himself, and should consult or deal with the ABS manufacturer or after-sales service department.

Tri Axle 40ft Flatbed Trailer for Sale In Tanzania

1. ABS combination valve leaks

When the tri axle 40 ft flatbed trailer ABS does not work, the air pressure of the control line of the ABS regulator entering the control air chamber of the ABS regulator and the output air pressure are in a 1:1 relationship, so when the control line entering the ABS control air chamber is controlled There is air leakage in the pipeline, which must cause the tri axle 40 ft flatbed trailer ABS output air pressure to decrease, and the ABS regulator to exhaust, causing the illusion of air leakage from the ABS regulator, which can be passed through the emergency relay valve and the ABS regulator.

Check the air pressure gauge between the control ports to see if the air pressure is stable when braking or pulling the handbrake. Therefore, when encountering such problems, be sure to check whether there is air leakage in the control pipeline, focusing on the key air leakage sources such as the emergency relay valve, tri axle 40 ft flatbed trailer brake valve, and handbrake valve. If there is no air leakage in the control line, it proves that the tri axle 40 ft flatbed trailer ABS regulator is leaking air, and the regulator should be replaced.

2. Gap code failure

The Tri axle 40 ft flatbed trailer ABS controller has a fault storage function. In order to better judge the fault, when the sensor gap is too large and the indicator light is always on after parking, the ABS indicator flashes the corresponding flash code after the key is turned on again.

The flash code judges that a certain wheel sensor has a large gap. In this case, please go to a professional service outlet or find a professional technician for repair. After the sensor gap is restored, the fault does not need to be cleared. At this time, start the tri axle 40 ft flatbed trailer to run the vehicle at a speed of 40km. The light will flash quickly, wait for the flashing to complete, the indicator will turn off and stop, then the fault will be cleared automatically.

Tri Axle 40ft Flatbed Trailer for Sale In Tanzania

3. Slow brake return

When the emergency relay valve in the control pipeline has poor air return when the brake is released or the handbrake is released, it will cause the brake to return slowly and cause dragging. This phenomenon is that the entire brake system has a slow return.

The brake system is slow in unilateral return, that is, the wheel on the same side of the tri axle 40 ft flatbed trailer for sale has slow brake return. Generally, there is a problem with the ABS regulator, and the regulator needs to be replaced. If the tri axle 40 ft flatbed trailer has insufficient air pressure in some of the air reservoirs, the spring brake air chamber cannot be opened, resulting in drag braking.

There is also very little water in the cooling water tank, when the air charge switch is turned on to cool the wheels, it will cause the air pressure in the tri axle 40 ft flatbed trailer air reservoir to drop very quickly The trailer air reservoir air pressure is too low, causing the spring brake air chamber to work And drag the brakes.

4. Air leakage of hand brake valve

The ABS valve exhaust port leaks air when it is in the hand brake, but the ABS valve does not leak air when the foot brake is on, but the working principle of the tri axle 40 ft flatbed trailer foot brake and hand brake is the same, which shows that the semi-trailer Part of the braking system is not faulty, check the tractor handbrake valve for air leakage or air leakage

Tri Axle 40ft Flatbed Trailer for Sale In Tanzania

You can learn about different types of flatbed semi trailer, such as 2 axle flatbed semi trailer,3 axle container semi trailer,4 axle 40ft flatbed semi trailer, etc. As well as the process, testing, packaging and customer feedback, etc.

This kind of semi trailer was designed with lots of advantages and features. If you want to get more information, please don't hesitate to make contact with us.
