4 Axle 100 Ton Detachable Gooseneck Trailer for Sale In Guinea

Guinea customers came to TITAN to consult about the business of 4 axle 100 ton detachable gooseneck trailer through a friend's introduction. Sales manager Annie introduced the 4 axle 100 ton detachable gooseneck trailer in detail and sent a detailed quotation and various detailed pictures and videos to the customer to help customers understand TITAN's 4 axle 100 ton detachable gooseneck trailer more systematically and quickly.

After a series of conversations, the customer finally chose TITAN among the 5 suppliers. Here's why to choose TITAN

4 Axle 100 Ton Detachable Gooseneck Trailer for Sale In Guinea

The gooseneck of the 4 axle 100 ton detachable gooseneck trailer has a downward pressure design, which can effectively prevent the detachable gooseneck trailer from tilting when loaded, making it easier to climb. Moreover, a double-layer vertical plate is used under the gooseneck to reinforce, so that the deformation amplitude will be relatively small when the vehicle is heavily loaded.

The side beams are all made of HG60 high-strength steel "H" type design. The bearing capacity is twice that of other steels, and it will not deform for 10 years.

The detachable gooseneck trailer suspension is thickened, 8mm thick, and the center axle is also 70mm. Moreover, the hanging rib is elongated, which can effectively prevent cracking and welding. We have reinforced the front, rear, left and right of the suspension, which can be applied to all road conditions in Africa.

Using 16 tons of brake pads, there are 220mm thick. The brake valve is also the used brand wabco. The wires are also waterproof wires.

4 Axle 100 Ton Detachable Gooseneck Trailer for Sale In Guinea

Features of 4 axle 100 ton detachable gooseneck trailer:

1. Strong carrying capacity

4 axle 100 ton detachable gooseneck trailer main girder adopts HG60 high strength structural steel. The yield strength of HG60 steel is ≥620MPa, which is more durable and stronger than ordinary steel. Its carrying capacity is 5 times that of Q345 steel trailer. TITAN lowboy trailers feature double-reinforced goosenecks and upper and lower panels.

2. Good performance

The load-bearing surface of the 4 axle 100 ton detachable gooseneck trailer can be adjusted to the ground level through hydraulic devices as required. When passing through culverts or bumpy roads, the load-bearing surface of the cargo platform can be lowered or raised to improve its passing performance.

3. Simple operation

The lifting operation handle of the bearing surface mostly adopts a centralized electric control device instead of the traditional handle to control the operation, which makes the operation interface more convenient.

The TITAN hydraulic system has undergone five major system upgrades in the ten-year production process, and now the hydraulic system has very good stability and stability, and customers only need regular maintenance. It can be used for ten years.

4 Axle 100 Ton Detachable Gooseneck Trailer for Sale In Guinea

4. Low center of gravity, good stability

Due to the low ground clearance and the low longitudinal beam height of this type of vehicle, its bearing surface is 300-400mm lower than the common concave center detachable low-rise semi-trailer, which effectively reduces the center height of the vehicle. The gravity of the loaded goods improves the stability during transportation.

5. Easy to maintain

Since the bearing surface can be raised and lowered, the tires on the bridge can be grounded, making it safe and convenient to change other tires or perform other maintenance work without disassembly.

6. The effective length of the cargo bed is long

Since this model cancels the rear ladder, the bearing surface can be lengthened, and because the construction machinery does not walk from the rear, the front slope angle of the bridge can be appropriately increased to lengthen the bearing surface. The length of the low-level cargo platform with a ladder at the end is longer, It can effectively load more goods, indirectly improve the loading efficiency, and create greater benefits for users.

4 Axle 100 Ton Detachable Gooseneck Trailer for Sale In Guinea

You can learn about different types of side wall semi trailers(like removable gooseneck trailer , removable gooseneck trailer for sale , 4 line 8 axle removable gooseneck trailer for sale in Nigeria). And the process, testing, packaging and customer feedback, etc.

This kind of semi trailer was designed with lots of advantages and features. If you want to get more information, please don't hesitate to make contact with us.
